Magni TH6.20 Telehandler

The TH 6.20 is a stationary telescopic handler ideally suited for demanding worksites. It excels in safely reaching heights of up to 19.20 meters on challenging terrain, thanks to its 4-wheel drive and an automated leveling system that operates on both the wheels and stabilizers. The hydrostatic transmission ensures precision and exceptional manoeuvrability.

This versatile machine is compatible with a wide variety of attachments and comes equipped with the R.F.ID system, enabling automatic attachment recognition and the generation of corresponding load charts. The TH 6.20 comes standard with the side-shift system, allowing lateral movement of the rear part of the chassis and the boom around the machine's longitudinal axis, effectively correcting the load's position without moving the entire unit. This system offers a shift of +/-5°, equivalent to a lateral movement of +/-1.5 meters when the boom is fully extended, regardless of the attached accessory.

Furthermore, the TH 6.20 is compliant with revelant standards and can be optionally equipped with a winch for working with suspended loads, enhancing its versatility and functionality.

Technical Features

• Stabilisers: Pivoting


• Lifting capacity: 6000 kg


• Capacity at maximum height: 2000 kg


• Lifting height: 19.20 m


• Reach: 14.40 m


• Engine: Deutz TCD 3,6 L4 Stage 3 or 5


• Rated power: 100 kW (136 hp) 2200 rpm


• Number of gears: 2/2


• Hydraulic system: 350 bar (Load Sensing)


• Length: 6.42m


• Width: 2.5m


• Ground clearance: 420 mm


• Unladen weight: 14,400 kg


• Travel speed: 40 km/h


• Climate control as standard: Yes


• Automatic accessory recognition: Yes
