Magni TH5.5-19P Telehandler

5.5 tonne / 19 metre

The TH5.5-19P is a stationary telescopic handler specifically designed for demanding light industrial environments. It is propelled by a Deutz engine with 75 kW of power, enabling safe operation at a remarkable height of 18.80 meters on challenging terrain. This capability is made possible by its 4-wheel drive system and an automated levelling mechanism that adjusts both the wheels and stabilizers to ensure stability even on rugged ground.

The hydrostatic transmission system provides precise control and exceptional manoeuvrability, enhancing its overall performance. This versatile machine is compatible with a diverse array of attachments, and it is equipped with the advanced R.F.ID system, which facilitates the automatic recognition of attachments and the generation of corresponding load charts.

Additionally, this model features a tire-based levelling system, giving the operator the ability to fine-tune the machine's inclination. This valuable feature ensures access to the complete load diagram for all types of operations, even when the natural slope of the terrain might impact lifting performance under typical conditions."

Technical Features

  • Stabilisers: Pivoting
  • Lifting capacity: 5500 kg
  • Capacity at maximum height: 3000 kg
  • Lifting height: 18.80 m
  • Reach: 14.10 m
  • Engine: Deutz TCD 3,6 L4 Stage 3 or 5
  • Rated power: 55,40 kW (75,30 hp) 2.200 rpm
  • Number of gears: 2/2
  • Hydraulic system: 350 bar (Load Sensing)
  • Length: 6.35 m
  • Width: 2.5m
  • Ground clearance: 400 mm
  • Unladen weight: 14,100 kg
  • Travel speed: 25 km/h
  • Climate control as standard: No
  • Automatic accessory recognition: Yes
