Magni TH7.10P Telehandler

The TH 7.10 is a fixed telescopic handler especially suitable for light industry. Powered by a Deutz engine, it can safely reach a height of 9.70 m on rough terrain thanks to its 4-wheel drive.

The hydrostatic transmission offers precision and manoeuvrability. This machine is compatible with a wide range of attachments. It is equipped with the R.F.ID system which allows for automatic recognition of attachments and the creation of the relative load charts.

This model is equipped with the levelling system on tyres allowing the operator to adjust the inclination of the machine. Thus, the entire load diagram is available for any type of operation, even when under normal conditions the slope of the terrain could affect lifting performance.

Specifications

• Lifting capacity: 7000 kg


• Lifting height: 9.70 m


• Engine: Deutz TCD 3,6 L4 Stage 3A /Stage 5 (Both in Stock)


• Number of gears: 2/2


• Hydraulic system: 350 bar Load Sensing


• Length: 6010 mm


• Width: 2530 mm


• Ground clearance: 410 mm


• Unladen weight: 12000 kg


• Travel speed: 25km/h


• Climate control as standard: Yes


• Automatic attachment recognition: Yes
